This kind mini wooden beads cnc wood lathe is with cheap cost for your choice to make the wood beads
with different sizes.
Parameters:
|
Machine Model |
Mini Wooden Beads Cnc Wood Lathe |
|
Place of Origin |
China |
|
Processing Size |
150mm Length x 70mm Diameter |
|
Max Feeding Material Length |
750mm |
|
Controller System |
Panel Controller System with Buttons |
|
Drive |
Yako 2d811 big drive |
|
Main Motor Power |
5.5KW |
|
Machine Weight |
400KG |
|
Ballscrew |
Imported TBI25 Ballscrew |
|
Machine Size |
2400x1500x1400mm |
|
Package Size |
2600*1700*2000mm |
Product Features:
1. The maximum turning diameter of this wood carving lathe: 70mm (diameter range from 0mm to 70mm).
2. Equipped with cylindrical wood automatic feeding platform.
3. Transmission mode: the cylinder moves automatically
4. Applicable drawing software: AutoCAD software, DXF. DWG.
5. The applicable working voltage is 220v or 380v, three-phase.
6. Oil pump: manual operation, automatic circulation, lubricating the whole machine, providing work efficiency
and service life.
Polishing function, to polish the wood beads during the process.
Panel controller with buttons and English language.
Automatic rack for pushing wood material.
Package and Delivery:
We can help arrange the shipping delivery based on your near port.
