1. Simple Introduction:
5 Axis Jewelry CNC Milling Machine-Small 5-Axis CNC Jewelry Engraving and Milling Machine
This kind machine is also called gold CNC engraving machine, silver CNC engraving machine,
gold CNC carving machine,gold CNC engraving milling machine, silver CNC milling machine,
It can processs all kinds of gold/silver rings, bracelets, beads, and three-dimensional pieces.
This model JM518 is a 5-axis CNC engraving machine equipped with an automatic tool change system.
Its A-axis cradle combined with C-axis rotation design offers enhanced stability and flexibility, allowing
complex 3D curved surface engraving to be completed in a single clamping.
2. Jewelry Applications:
All kinds of bracelets.
3. Parameters:
|
Machine Model |
5 Axis Jewelry Cnc Milling Machine-JM518 |
|
Place of Origin |
China |
|
XYZ Tavel |
230x260x180mm |
|
Working Diameter/Height |
100x100mm |
|
XYZ Axis Positioning Accuracy |
0.01/0.01/0.01mm |
|
A/C Axis Positioning Accuracy |
0.01° |
|
XYZ Axis Repeat Positioning Accuracy |
0.01/0.01/0.01mm |
|
A/C Axis Repeat Positioning Accuracy |
0.01° |
| A/C Axis Rotation Angle | -30+120°/360°
|
|
Spindle Power |
2.4kw |
|
Spindle Type |
Tool change Servo Electric Spindle |
|
Spindle Max Speed |
0-60000rpm/miin |
| Spindle Cooling Method | Watercooling/Oil Cooling |
|
Tool Magazine Capacity |
12 disk knife magazines |
|
Tool Holder Type |
T11-ER11-23 |
| Transmission Screw/ Liner Guide | Ground Ball Screw/ H-grade liner guideways |
| Drive System | Bus Servo(Absolute Type) |
| Working Voltage | 220V, 50hz |
| Overall Dimensions | 800x920x1850mm |
| Machine Frame | Integral Cast Iron, Stainless Steel, Sheet Metal |
| Whole Machine Weight | 605kg |
| Total Machine Power | 4.8kw |
|
Controller system |
Five-axis CNC system with RTCP functionality |
| Guarantee | 2 years for free, lifetime warranty |
4. Small 5 Axis Jewelry Cnc Milling Machine Details:
Automatic Tool Change System:
Equipped with a 12-tool disc-type magazine,it eliminates the need for manual tool changing,significantly
improving machining efficiency.
Installed with the custom chuck to fix the gold/silver rings, bracelets,pendants, beads etc.
The system enables programming-free machining, as it comes pre-loaded with toolpath files for various
designs,which can be directly selected for immediate use, offering exceptional convenience and ease of operation.
Equipped with RTCP(Rotation Tool Center Point) functionality, it ensures high precision, efficiency , and
flexibility when processing complex curved surfaces, fine details, and multi-angle machining tasks.
A funnel-style processing chamber designed specifically for precious metal machining enables convenient
recovery with a rate reaching 99.8% to 99.9%.
