Jinan APEX CNC Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of composite material cutting machine in China. With abundant experience, we warmly welcome you to buy advanced composite material cutting machine for sale here from our factory. Good service and quality products are available.

Working Demo:

Machine Introduction:

This composite material cutting machine has three powerful functions, including Huadiao high-speed spindle,

intelligent edge patrol system, and high-frequency vibrating knife.
The 1325 high-speed composite cutting machine is equipped with a high-frequency electric vibrating knife + 3kw

spindle 40,000RPM as standard. It has the functions of engraving hard materials and cutting flexible materials.

It can quickly complete full cutting, half cutting, engraving and milling, contour recognition, and cutting processes.

The operating system is safe and simple, and it is easy to learn and operate. This kind composite wood CNC machine

is your best choice for your startup business.

composite material cutting machine and cnc machines for wood working 2

composite material cutting machine and cnc machines for wood working 1

composite material cutting machine and cnc machines for wood working 3

composite material cutting machine and cnc machines for wood working 4

Specification Parameters:

Machine Model	1325-1 Composite Material Cutting Machine
Processing Size	1300mm Wide x 2500mm Length
CNC Controller	Hand DSP Remote Controller/ NCstudio Controller
Motor and Drive	Stepper model
Square and Slider	Imported Taiwan Hiwin Square and Slider
Spindle	3.5KW China Top Brand Aircooling Spindle, 0-18000RPM
Oscillating knife	High-frequency, suitable for cutting flexible materials with fast cutting speed
Machine Weight	1200KG
Frequency Inverter	Best frequency inverter
Ballscrew	Imported TBI25 Ballscrew
Package Size	3200x2200x2100mm
Software Compatibility	Type3/JDpaint Software, (Option: Artcam Software)
Working Voltage	220V,3 phase or 380V,3 phase

Machine Configuration Details:

The 3 main function:

1).Mini character processing: fast cutting speed, high precision and good effect.

2). High-frequency vibrating knife cutting: fast cutting speed, high precision and small incision. It can cut KT board,

non-stick glue and other advertising processing industries.

3). Intelligent edge patrol system: high-definition scanning, precision processing.

composite material cutting machine servo motor and drive

Drive motor: High-precision Leisai 750W servo motor with large torque, strong stability and anti-interference.

Equipped with Wilfa high-precision reducer to improve the speed and precision of the equipment.

composite material cutting machine controller

Control system: Xingduowei control system, industrial grade, anti-interference, network cable link.

Edge patrol function: high-resolution CCD positioning, intelligent visual edge patrol.

composite material cutting machine watercooling spindle

Huadiao high-speed spindle: 40,000 revolutions per minute, using precision ceramic bearings to ensure the rotation

accuracy and durability of the spindle during high-speed grinding. Equipped with 5200 chiller.

composite material cutting machine oscillating knife

High-frequency oscillating/ vibrating knife: suitable for cutting flexible materials with fast cutting speed.

composite material cutting machine square guide rail

Guide rail rack: Taiwan Hiwin 25mm high-precision guide rail, 1.5M grinding rack, equipped with automatic oil

injection system.

Heavy-duty bed, aviation aluminum beam. After aging treatment and five-axis metal processing center processing,

the aviation aluminum beam is stable and does not deform, and the running speed is fast.

oscillating knife composite material cutting machine

Vacuum adsorption table, equipped with 5.5kw vacuum pump.

Applicable Samples:

This composite material cutting machine CNC is widely used in mini character processing, acrylic cutting, MDF cutting,

two-color board engraving, various advertising plates, logo production, printing and packaging, clothing samples, shoes,

hats, bags, automotive interiors, home textiles, sealing gaskets, corrugated paper, honeycomb Cardboard, carpet mats

and other industries.

1.Woodworking machining: Wooden door, furniture and decoration, Cabinet Making, Wood crafts making, Redwood

carving, Archaized furniture and other industries.

2.Advertising Processing: Double face board and scutcheon, department brand, chest brand and the architecture

board, ABS brand, acrylic and jade article.

3.Electronic Machining: Circuit, insulation materials, LED screen, family appliance shell and model carving.

4.Die industry: copper sculpture, aluminum engrave, metal molds, plastic sheeting, PVC, etc;

5.Decoration: acrylic, density board, artificial stone, organic glass, soft metals like aluminum and copper.

composite material cutting machine and cnc machines for wood working application

corrugated paper and Honeycomb cardboard cutting machine

Non-stick cutting samples 1

Non-stick cutting samples 2

Machine Package:

1. Outer packing: standard export plywood box for 1325 3 axis CNC router;
2. Inner packing: stretch film and moisture-proof plastic film.

Port: Qingdao/Shanghai/Yiwu/Guangzhou/Tianjin.

Delivery Terms:
1) The CNC equipment will be manufactured after received your downpayment, it need 26 working days around to

produce the equipment after get your downpayment.
2) After the machine is finished, we will test it very carefully, and to make sure everything is in good condition.
3) Then we will show you the equipment with photos and the testing video.
4) After you agree, please arrange the balance payment before delivery.
5) Finally, everything is tested well, then we will arrange the delivery.

Composite Material Cutting Machine package and delivery
